Uninterruptible power supply SNR-UPS-ONRT-2000-INT, on-line, 2000 VA, 36VDC, with batteries

SNR-UPS-ONRT-2000-INT

$ 599.00
On-line, Rack/Tower, 2000VA/1800W, 220-240VAC (50/60Hz), 1ph+N+PE, 72VDC, 6 outlets IEC C13, USB/RS232/SNMP, with batteries - 6x9Ah

Technical Specifications

  • Type of UPS Rack Tower
  • Total capacitance, A 9
  • Weight, kg (1) 25
  • Operating temperature, °C (1) 0
    40
  • Phase 1
  • Input voltage 110-288 V
  • Battery type Lead-acid
  • Type of UPS (1) On-line

Product Info

Part number: SNR-UPS-ONRT-2000-INT

The uninterruptible power supply on-line SNR of the Intelligent 2000 series VA, 72VDC is made according to the scheme with double conversion (on-line). It provides a load with a stabilized sinusoidal voltage and is designed to provide an uninterrupted power supply to the server, telecommunications, networks, and industrial equipment.

Through the RS232 interface, it is possible to connect to a PC and configure the display of the UPS status on the PC monitor. The presence of a slot for the SNMP adapter will allow you to organize monitoring of the UPS through the network.

Power failures can occur at unpredictable times, and the quality of electricity can also change over time. Power supply problems are dangerous for IT equipment, leading to damage to important data, loss of unsaved work sessions, and equipment failure - all this can result in many hours of downtime and expensive repairs.SNR uninterruptible power supplies easily solve these problems, providing high reliability.

Main advantages:

  • Extended operating range of the input network, the voltage from 110 to 288 V;

  • Synchronization of the UPS output network with the input network in various frequency ranges allows for a reliable power supply of the load;

  • High input power factor;

  • No impact on the input network;

  • Maintaining operability at low input voltage;

  • Reliable UPS protection functions;

  • Wide input voltage range, high efficiency;

  • Cold start without using extraneous utilities;

  • Advanced RS232 communication with software and optional USB communication port

  • Possibility to install an SNMP card or a dry contact card;

  • Automatic fan speed adjustment;

  • Overload and short circuit protection;

  • Default ECO functions;

  • Low noise level;

  • Built-in electromagnetic and radio interference filter.

Scope of delivery

  • UPS user manual

  • Software CD

  • USB cable

  • RS232 cable

  • brackets for rack mounting

  • C20-C19 power cable

  • C14-C13 power cable

  • to install SNR uninterruptible power supplies in the rack, we offer you a universal sledSNR-UPS-RK. (Sold separately)




Technical Specifications

  • Type of UPS Rack Tower
  • Total capacitance, A 9
  • Weight, kg (1) 25
  • Operating temperature, °C (1) 0
    40
  • Phase 1
  • Input voltage 110-288 V
  • Battery type Lead-acid
  • Type of UPS (1) On-line
  • Dimension, mm (1) 173(4U)x438x477
  • COM port DB9 port
    USB)
  • Maximum number of lines 1
  • Percentage of moisture 0 – 90%
  • Number of batteries 6
  • Hour battery rating, A 9
  • Battery charging current, A 1
  • Expiratory phase 1
  • Output Voltage 200/208/220/230/240 V (AC)
  • Type and number of outlet sockets IEC 320 C13 x 6
  • Battery voltage 72
  • Input connections IEC320 C14
  • Backup power supply time at 50% load 17 minutes
  • Output power factor, RF 0,9
  • Power, VA 2000
  • Power, W 1800
  • Efficiency in mains operation 90%
  • Intput frequency, Hz 40-70
  • Output frequency, Hz 50/60
